Features of ANTEC CX500M Basic ATX Mini Tower Cabinet ( Black )





Introducing the Antec CX500M Basic Gaming Chassis, which is designed for gamers who want both style and performance. Its panoramic design provides a sleek, transparent appearance that highlights your hardware beautifully. The tool-free glass side and front panels feature a clip design for easy and safe installation, while the bottom mesh exterior improves cooling efficiency and prevents heat buildup. The CX500M Basic allows for up to 9 fans and a 360mm water cooling radiator on top, ensuring rapid heat dissipation and optimal performance.

The CX500M Basic has a 5-slot PCIe design that improves graphics card compatibility and provides more cooling space, reducing the risk of overheating. Additional features include a removable hard drive cage, magnetic top and bottom dust filters for clean air intake, and a Type-C 3.2 Gen 2 port for fast data transfer. It includes two 120mm reverse blade fans on the sides and one 120mm fan in the back, which are pre-connected for easy setup. Enhance your gaming experience with the Antec CX500M Basic Gaming Chassis.

1. Panoramic 270° design for a transparent and sleek look.
2. Tool-free glass side and front panels with a clip design for easy and safe installation.
3. Vertical airflow supports up to 9 fans, speeding up heat dissipation.
4. Includes a Type-C 3.2 Gen 2 port for high-speed data transfer.
5. Top and Bottom Magnetic Dust Filters



Specifications of ANTEC CX500M Basic ATX Mini Tower Cabinet ( Black )





Brand	Antec
Series	CX Series
Model	CX500M Basic (0-761345-10112-7)
Physical Details
Colour	Black
Materials	Aluminium
Steel
Tempered Glass
Side Panel	4mm Tempered Glass (front, side), partial mesh (right side)
Front I/O	1x USB 5Gbps Type-A Port (Front Panel)
	2x USB 2.0 Type-A Ports (Front Panel)
	1x 3.5mm Combination Audio Jack (Front Panel)
Motherboard Support	Micro-ATX, Mini-ITX
Expansion Slots	5x Vertical PCI Slots
Drive Bays	1x 2.5″/3.5″ Combo Drive Bay (Removable)
1x 3.5″ Drive Bay (Removable)
1x 2.5″ Drive Bay (Behind motherboard tray)
PSU Support	ATX
Dimensions	436 x 446 x 210mm (D x H x W)
Weight	5.9kg
Pre-Installed Fans
Side	N/A
Bottom	N/A
Rear	N/A
Fan Support
Top	3x 120mm or 2x 140mm fans
Side	2x 120mm fans
PSU Shroud	3x 120mm fans
Rear	1x 120mm fan
Radiator Support
Top	120, 140, 240, 280, 360mm support
Side	N/A
PSU Shroud	N/A
Rear	N/A
Clearance
Motherboard Tray Width	N/A
CPU Cooler Height Limitation	Up to 165mm
GPU Length Limitation	Up to 415mm
PSU Length Limitation	Up to 210mm with HDD cage
Up to 270mm without HDD cage
Cable Management	Yes, 23mm depth behind motherboard tray
General
Dust Filters	Yes, top & bottom removable
Chassis Lighting	N/A
Warranty Information
Warranty	1 Year Warranty
