Features of DEEPCOOL CC560 V2 ATX Mid Tower Cabinet (Black)





The DeepCool CC560 WH Mid-Tower computer cpu case in White offers outstanding value with spacious component compatibility, a full-sized tempered glass window, and a total of four pre-installed LED fans that gets any build started right.

Abundant Airflow Performance

Well ventilated throughout the entire chassis, the CC560 sports an airflow front panel and a large mesh top panel to ensure fresh air is circulating.

Primed and Ready

deepcool cabinet CC560 V2 come with 4 pre-installed LED fans delivers big airflow performance ensuring any system build is receiving top-notch cooling capacity.

Wide Cooling Support

DEEPCOOL CC560 V2 ATX Cabinet support high-performance AIO liquid coolers with room for 360mm radiators in front or 240mm on top. Cooling fan support for up to 6x 120mm or 4x 140mm.

Storage Solutions

Install up to 2x 2.5” SSDs directly on the backplate and 2x 3.5” HDDs underneath the shroud in a removeable drive cage for adjustability.



Specifications of DEEPCOOL CC560 V2 ATX Mid Tower Cabinet (Black)



Product Dimensions	416×210×477mm(L×W×H)
Net Weight	5.25Kg
Materials	ABS+SPCC+Tempered Glass
Motherboard Support	Mini-ITX / Micro-ATX / ATX
Front I/O Ports	USB3.0×1、USB2.0×1、Audio×1
3.5" Drive Bays	2
2.5" Drive Bays	2+1
Expansion Slots	7 Slots
Pre-Installed Fans	Front: 3×120mm Rear: 1×120mm
Fan Support	Front: 3×120 / 2×140mm Top: 2×120 / 2×140mm Rear: 1×120mm
Radiator Support	Front: 120/140/240/280/360mm Top: 120/240mm Rear: 120mm
CPU Cooler Height Limit	163mm
GPU Length Limit	370mm
Power Supply Type	ATX PS2（maximum length: 170mm）
EAN Code	6933412714880
PN Code	R-CC560-BKGAA4-G-1
