MSI MPG Z790 Edge Ti Max Wifi DDR5 Intel Motherboard
Features Of MSI MPG Z790 Edge Ti Max Wifi DDR5 Intel Motherboard
Â
Give your gaming rig a quality boost with the MSI MPG Z790 EDGE TI MAX WIFI, a top-tier motherboard that offers an excellent set of advanced features. The motherboard belongs to the elite category offering stable performance and broad compatibility. Whether you’re building a gaming powerhouse or a robust home computing system, the MSI MPG Z790 EDGE TI MAX WIFI motherboard will deliver the performance to match your needs.
- Supports Intel® Core™ Next-gen / 13th Gen / 12th Gen, Pentium® Gold and Celeron® processors for LGA 1700 socket
- Supports DDR5 Memory, up to 7800+(OC) MHz
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2, USB 3.2 Gen 2Ă—2
- Enhanced Power Design: 16+1+1 Mirrored Power Arrangement, dual 8-pin CPU power connectors, Core Boost, Memory Boost
- Premium Thermal Solution: Enlarged heatsink with heat-pipe, MOSFET thermal pads rated for 7W/mk, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
- 2.5G LAN and Wi-Fi 7 Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
- High Quality PCB: 6-layer PCB made by server grade level material
- Pre-installed I/O Shield: Better EMI protection and more convenience for installation
The MSI MPG Z790 EDGE TI MAX WIFI DDR5 motherboard  is a premium product in the MSI MPG (MAG) motherboard line and is designed to meet the needs of gamers and professionals in the field. information technology. With DDR5 support, this is a powerful motherboard capable of running high-performance applications and games.
Energy solutions
The MSI MPG Z790 EDGE TI MAX WIFI motherboard  is equipped with a class-leading VRM design with a total of 16+1+1 direct power phases. This combination of dual power connectors and 90A Smart Power Stage provides enhanced performance and robust response with high-end processors. The new PCB design is also optimized to increase bandwidth and improve data transfer speeds, while also improving circuit transmission, creating ideal conditions for stable and reliable system operation.Â
DIY friendly
MSI MPG Z790 EDGE TI MAX WIFI DDR5 motherboard  offers an aesthetic design with a delicate white color scheme, combined with vivid RGB lighting. This not only accents your system, but also allows you to customize your gaming space to your personal style.
This design is patented and is particularly impressive for its ability to install M.2 drives and Shield Frozr without using annoying screws. This makes the installation process simpler and more convenient, helping you save time and enhance your system building experience.
Peak performance
MSI MPG Z790 EDGE TI MAX WIFI DDR5 supports a wide range of the latest storage standards, helping users connect to any storage device quickly. This helps you start the game faster, reduces level loading times, and gives you a real edge when competing against your opponents.
Powerful heat dissipation
The MSI MPG Z790 EDGE TI MAX WIFI DDR5 motherboard allows you to manage the speed and temperature of the entire system along with the CPU fan through both the BIOS and the easy-to-use included software. Additionally, you have the ability to set up to 4 temperature thresholds, and the cooling fan will operate automatically when the temperature reaches the set value. In particular, the MSI MPG Z790 EDGE WIFI is equipped with MSI AI ENGINE, allowing it to detect and automatically adjust the speed of the system fan based on the temperature rise of the CPU and GPU, ensuring that the system always operates. Stable and cool.
Latest memory
A breakthrough in enhancing motherboard performance lies in its ability to support the latest DDR5 memory. When combined with specialized SMT (Surface Mount Technology) soldering process and MSI Memory Boost technology, MSI MPG Z790 EDGE TI MAX WIFI is ready to deliver ultimate memory performance. XMP (Extreme Memory Profile) technology in MSI BIOS has been tested and certified by MSI OC LAB, making it easy to enable automatic settings to achieve optimal memory speed and stability.
Beautiful RGB lighting system
MSI MPG Z790 EDGE TI MAX WIFI offers a diverse range of RGB lighting colors and effects through the MSI Mystic Light app. With support for 16.8 million colors and impressive LED lighting effects, you have the power to create a desktop space as unique and stylish as you want. More importantly, you have full control and customization of your PC system’s RGB lighting capabilities through the included intuitive software, helping you create a unique and personalized experience environment.
Â
Specifications Of MSI MPG Z790 Edge Ti Max Wifi DDR5 Intel Motherboard
Â
Â
| Model | MPG Z790 EDGE TI MAX WIFI |
| Chipset | INTEL Z790 |
| CPU SUPPORT |
Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700 |
| Memory |
4x DDR5 UDIMM, Maximum Memory Capacity 192GB Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 7800+ MHz • 1DPC 2R Max speed up to 6600+ MHz • 2DPC 1R Max speed up to 6400+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Intel® XMP3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
| Onboard Graphics |
1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 8K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| EXPANSION SLOT |
2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Storage |
5x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 8x SATA 6G |
| RAID |
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices * SATA_A1~A2 do not support RAID function. |
| USB |
4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 4x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) |
| LAN | Intel® 2.5Gbps LAN |
| WIRELESS / BLUETOOTH |
Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.4**, MLO, 4KQAM * 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 SV3. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor's website for details. Bluetooth 5.4 support schedule depends on MSFT Windows 11 plan. |
| Audio |
Realtek® ALC4080 Codec 7.1-Channel USB High Performance Audio Supports up to 32-Bit/384 kHz playback on front panel |
| Internal I/O |
1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports 1x ARGB+FAN Header (JAF_1) 1x USB4 card connector (JTBT_U4_1, supports RTD3) |
| LED FEATURE |
4x EZ Debug LED 1x EZ LED Control switch |
| BACK PANEL PORTS |
Display Port USB 3.2 Gen 1 5 Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-A) 2.5G LAN Audio Connectors HDMI™ Clear CMOS Flash BIOS USB 3.2 Gen 2 10Gbps (Type-C) USB 3.2 Gen 2x2 20Gbps (Type-C) Wi-Fi / Bluetooth Optical S/PDIF Out |
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB Dimension (W Ă— L) |
ATX 243.84mmx304.8mm |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice |
Â
Features Of MSI MPG Z790 Edge Ti Max Wifi DDR5 Intel Motherboard
Â
Give your gaming rig a quality boost with the MSI MPG Z790 EDGE TI MAX WIFI, a top-tier motherboard that offers an excellent set of advanced features. The motherboard belongs to the elite category offering stable performance and broad compatibility. Whether you’re building a gaming powerhouse or a robust home computing system, the MSI MPG Z790 EDGE TI MAX WIFI motherboard will deliver the performance to match your needs.
- Supports Intel® Core™ Next-gen / 13th Gen / 12th Gen, Pentium® Gold and Celeron® processors for LGA 1700 socket
- Supports DDR5 Memory, up to 7800+(OC) MHz
- Lightning Fast Game experience: PCIe 5.0 slot, Lightning Gen 5 x4 M.2, USB 3.2 Gen 2Ă—2
- Enhanced Power Design: 16+1+1 Mirrored Power Arrangement, dual 8-pin CPU power connectors, Core Boost, Memory Boost
- Premium Thermal Solution: Enlarged heatsink with heat-pipe, MOSFET thermal pads rated for 7W/mk, additional choke thermal pads and M.2 Shield Frozr are built for high performance system and non-stop gaming experience
- 2.5G LAN and Wi-Fi 7 Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
- AUDIO BOOST 5: Reward your ears with studio grade sound quality for the most immersive gaming experience
- High Quality PCB: 6-layer PCB made by server grade level material
- Pre-installed I/O Shield: Better EMI protection and more convenience for installation
The MSI MPG Z790 EDGE TI MAX WIFI DDR5 motherboard  is a premium product in the MSI MPG (MAG) motherboard line and is designed to meet the needs of gamers and professionals in the field. information technology. With DDR5 support, this is a powerful motherboard capable of running high-performance applications and games.
Energy solutions
The MSI MPG Z790 EDGE TI MAX WIFI motherboard  is equipped with a class-leading VRM design with a total of 16+1+1 direct power phases. This combination of dual power connectors and 90A Smart Power Stage provides enhanced performance and robust response with high-end processors. The new PCB design is also optimized to increase bandwidth and improve data transfer speeds, while also improving circuit transmission, creating ideal conditions for stable and reliable system operation.Â
DIY friendly
MSI MPG Z790 EDGE TI MAX WIFI DDR5 motherboard  offers an aesthetic design with a delicate white color scheme, combined with vivid RGB lighting. This not only accents your system, but also allows you to customize your gaming space to your personal style.
This design is patented and is particularly impressive for its ability to install M.2 drives and Shield Frozr without using annoying screws. This makes the installation process simpler and more convenient, helping you save time and enhance your system building experience.
Peak performance
MSI MPG Z790 EDGE TI MAX WIFI DDR5 supports a wide range of the latest storage standards, helping users connect to any storage device quickly. This helps you start the game faster, reduces level loading times, and gives you a real edge when competing against your opponents.
Powerful heat dissipation
The MSI MPG Z790 EDGE TI MAX WIFI DDR5 motherboard allows you to manage the speed and temperature of the entire system along with the CPU fan through both the BIOS and the easy-to-use included software. Additionally, you have the ability to set up to 4 temperature thresholds, and the cooling fan will operate automatically when the temperature reaches the set value. In particular, the MSI MPG Z790 EDGE WIFI is equipped with MSI AI ENGINE, allowing it to detect and automatically adjust the speed of the system fan based on the temperature rise of the CPU and GPU, ensuring that the system always operates. Stable and cool.
Latest memory
A breakthrough in enhancing motherboard performance lies in its ability to support the latest DDR5 memory. When combined with specialized SMT (Surface Mount Technology) soldering process and MSI Memory Boost technology, MSI MPG Z790 EDGE TI MAX WIFI is ready to deliver ultimate memory performance. XMP (Extreme Memory Profile) technology in MSI BIOS has been tested and certified by MSI OC LAB, making it easy to enable automatic settings to achieve optimal memory speed and stability.
Beautiful RGB lighting system
MSI MPG Z790 EDGE TI MAX WIFI offers a diverse range of RGB lighting colors and effects through the MSI Mystic Light app. With support for 16.8 million colors and impressive LED lighting effects, you have the power to create a desktop space as unique and stylish as you want. More importantly, you have full control and customization of your PC system’s RGB lighting capabilities through the included intuitive software, helping you create a unique and personalized experience environment.
Â
Specifications Of MSI MPG Z790 Edge Ti Max Wifi DDR5 Intel Motherboard
Â
Â
| Model | MPG Z790 EDGE TI MAX WIFI |
| Chipset | INTEL Z790 |
| CPU SUPPORT |
Support Intel® Core™ 14th/ 13th/ 12th Gen Processors, Intel® Pentium® Gold and Celeron® Processors LGA 1700 |
| Memory |
4x DDR5 UDIMM, Maximum Memory Capacity 192GB Memory Support 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(JEDEC)/ 5400(JEDEC)/ 5200(JEDEC)/ 5000(JEDEC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 7800+ MHz • 1DPC 2R Max speed up to 6600+ MHz • 2DPC 1R Max speed up to 6400+ MHz • 2DPC 2R Max speed up to 5600+ MHz Supports Intel® XMP3.0 OC Supports Dual-Controller Dual-Channel mode Supports non-ECC, un-buffered memory |
| Onboard Graphics |
1x HDMI™ Support HDMI™ 2.1, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 8K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed. |
| EXPANSION SLOT |
2x PCI-E x16 slot 1x PCI-E x1 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset) |
| Storage |
5x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110/2280/2260 devices M.2_2 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 / SATA mode, supports 2280/2260/2242 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260/2242 devices M.2_5 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices 8x SATA 6G |
| RAID |
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices * SATA_A1~A2 do not support RAID function. |
| USB |
4x USB 2.0 (Front) 4x USB 3.2 Gen1 Type A (Rear) 2x USB 3.2 Gen1 Type A (Front) 4x USB 3.2 Gen2 Type A (Rear) 1x USB 3.2 Gen2 Type C (Rear) 1x USB 3.2 Gen2 Type C (Front) 1x USB 3.2 Gen2x2 Type C (Rear) |
| LAN | Intel® 2.5Gbps LAN |
| WIRELESS / BLUETOOTH |
Wi-Fi 7 Solution The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz* (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.4**, MLO, 4KQAM * 6GHz band support may depend on every country’s regulations and Wi-Fi 7 will be ready in Windows 11 SV3. ** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor's website for details. Bluetooth 5.4 support schedule depends on MSFT Windows 11 plan. |
| Audio |
Realtek® ALC4080 Codec 7.1-Channel USB High Performance Audio Supports up to 32-Bit/384 kHz playback on front panel |
| Internal I/O |
1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 6x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 3.2 Gen1 Type A ports 1x USB 3.2 Gen2 Type C ports 1x ARGB+FAN Header (JAF_1) 1x USB4 card connector (JTBT_U4_1, supports RTD3) |
| LED FEATURE |
4x EZ Debug LED 1x EZ LED Control switch |
| BACK PANEL PORTS |
Display Port USB 3.2 Gen 1 5 Gbps (Type-A) USB 3.2 Gen 2 10Gbps (Type-A) 2.5G LAN Audio Connectors HDMI™ Clear CMOS Flash BIOS USB 3.2 Gen 2 10Gbps (Type-C) USB 3.2 Gen 2x2 20Gbps (Type-C) Wi-Fi / Bluetooth Optical S/PDIF Out |
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB Dimension (W Ă— L) |
ATX 243.84mmx304.8mm |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice |
